800 kV Y Suspension Insulators Fittings are typically used in transmission lines where the conductors are suspended between supporting structures such as poles or towers. Suspension insulators consist of a series of insulating discs or units connected by metal fittings and are designed to provide electrical insulation while also supporting the weight of the conductors under tension.
Inquiry Now
Send Email To Us
  • Product Details
  • Company
  • Product FAQ

mechanical support and electrical insulation.

800 kV Y suspension insulator fitting combines high-strength materials, optimized disc count, corona control, and pollution-resistant design. The Y-configuration enhances mechanical stability, while rigorous testing ensures performance under extreme electrical and environmental conditions. They are used to connect insulators to conductors, towers, or substation equipment, while maintaining


Purpose and Configuration:

Function: Support conductors on high-voltage transmission lines while providing electrical isolation from towers.

Y Configuration: Typically involves a yoke plate splitting into two arms, forming a V-shape (resembling a Y from the side), enhancing mechanical stability and reducing wind-induced oscillations.


Insulator Discs:
Number of Discs: Approximately 35-45 units, depending on environmental factors (pollution, humidity). Each disc handles ~15-22 kV, with adjustments for safety and contamination.


Key Components:

Yoke Plates: Connect insulator strings to the tower and conductor, distributing mechanical load.

Corona Rings/Grading Rings: Mitigate corona discharge by smoothing electric field distribution, critical at 800 kV.

Hardware: High-strength steel/aluminum alloy shackles, thimbles, and suspension clamps to handle mechanical stresses (tension, wind, ice).

insulator hardware fittings equipments

insulator hardware fittings types
insulator hardware fittings specifiction

insulator hardware fittings
