220 kV Single Suspension Insulator Hardware Fitting is a critical component in high-voltage transmission systems, designed to support conductors in straight-line spans while maintaining electrical insulation.
Inquiry Now
Send Email To Us
  • Product Details
  • Company
  • Product FAQ

Key Components and Functionality

Voltage Rating (220 kV):
Optimized for high-voltage applications, ensuring adequate electrical insulation to prevent flashovers or leakage currents.
Designed with smooth contours to minimize corona discharge, even under wet or polluted conditions.


Single Suspension Design:

Vertical Load Support: Primarily handles the weight of the conductor and moderate wind/ice loads in straight-line spans (suspension towers).
Flexibility: Allows slight horizontal movement due to thermal expansion/contraction or wind sway, reducing stress on the tower and conductor.
Simpler Configuration: Uses a single string of insulators (vs. double tension’s dual strings), making it lighter and more economical for standard spans.


Hardware Components:
Socket/Clevis: Connects the insulator string to the tower (upper end) and the conductor (lower end).
Suspension Clamp: Grips the conductor securely while distributing mechanical load evenly.
Ball-and-Socket or Tongue-and-Clevis Links: Enable articulation to accommodate movement without overstressing the glass insulators.


Glass Insulators:
Advantages: High mechanical strength (~80–120 kN), resistance to environmental degradation, and easy visual inspection for cracks or punctures.
Fitting Compatibility: Hardware is designed to avoid point-load stresses on brittle glass, often using cushioning sleeves or forged connectors.

220 kV Single Suspension Insulators Hardware Fittings equipments

insulator hardware fittings types
insulator hardware fittings specifiction

insulator hardware fittings
