765 kV Double Tension Fitting for Quad Conductor is a specialized fitting used in ultra-high voltage transmission lines, particularly for 765 kV power systems. The term "quad conductor" refers to the use of four conductors (per phase) for carrying electricity. This setup helps balance the electrical load and maintain the required spacing between conductors in high-voltage systems.
Inquiry Now
Send Email To Us
  • Product Details
  • Company
  • Product FAQ

Key Features:

Voltage Rating: Designed specifically for 765 kV, the highest voltage typically used in long-distance, high-capacity transmission lines.
Double Tension Design: This fitting is designed for double tension—it can support two conductors per phase, providing extra mechanical strength and helping to distribute the load evenly across the transmission line.
Quad Conductor Setup: The fitting supports four conductors per phase (two per side), helping to ensure efficient electrical flow and reduce losses over long distances.
Material Construction: Typically made of high-strength, corrosion-resistant materials like galvanized steel, aluminum alloy, or composite materials, ensuring durability and resistance to extreme weather conditions and mechanical stress.
Load-bearing Capacity: Capable of withstanding high mechanical loads such as wind, ice, and conductor tension, which are prevalent in high-voltage transmission systems.
Mechanical and Electrical Insulation: Often includes insulation or integrated insulators to avoid electrical faults, flashover, or short circuits, ensuring safety in operation.
Adjustable Design: These fittings allow for adjustments in the conductor's position, providing flexibility during installation and maintenance.

Applications:

765 kV Power Transmission Lines: This fitting is primarily used in ultra-high voltage power transmission systems, particularly in areas requiring the transmission of large amounts of electricity over long distances.
Long-Distance Electrical Grids: It is essential for maintaining stable and reliable power flow in large regional or national grids.
High-Capacity Power Lines: Designed for high-capacity transmission lines that require multiple conductors per phase to increase current-carrying capacity and reduce line losses.

Benefits:

Enhanced Electrical Capacity: By using quad conductors, the system can carry more power while maintaining lower line losses, making it ideal for long-distance transmission.
Increased Stability: The double tension design helps in balancing the mechanical load, reducing the chance of sagging or misalignment of conductors over time.
Durability: The material construction ensures resistance to corrosion, ensuring the fittings will last for many years, even in harsh environments.
Flexibility in Installation: The fittings are designed to be versatile, accommodating different configurations and conductor types, thus optimizing system performance.
Reduced Maintenance Costs: The robust design and materials reduce the likelihood of frequent maintenance or replacement, helping to lower long-term operational costs.
