U100b Double Shell Two Winged Glass Insulator 146 280 450 is a high voltage glass insulator with a 146 mm socket, 280 mm diameter, and 450 mm creepage distance, designed for robust electrical insulation in polluted or foggy environments. These U100b glass insulators are designed for overhead power lines requiring robust mechanical and electrical insulation performance, especially in challenging environmental conditions and networks with bird protection needs.
Inquiry Now
Send Email To Us
  • Product Details
  • Company
  • Product FAQ
U100 Double Shell Two Winged Glass Insulator with specifications 146, 280, 450 refers to a high voltage glass insulator characterized by:

Socket coupling diameter: 146 mm
Overall diameter: 280 mm

Creepage distance: 450 mm

ThiThis type of powerline insulator is typically used in powerline applications and is designed to resist pollution and fog effects, enhancing its insulation performance under adverse environmental conditions. The "Double Shed" or "Double Shell" design increases the creepage distance, which helps prevent electrical leakage and flashover. The "Two Winged" description likely refers to the shape or configuration of the sheds (the protruding rings) on the insulator that increase surface distance for electrical insulation.

glass insulator types Voltage（KV） glass insulator types Voltage（KV）
Fog type glass insulator U70BLP 10KV-330KV Standard type glass insulator U40B 10KV-66KV
U70BLP1 10KV-330KV U70BS 10KV-330KV
U70BLP2 10KV-330KV U70BL 10KV-330KV
U80BLP 10KV-330KV U100BS 10KV-330KV
U80BLP1 10KV-330KV U100BL 10KV-330KV
U100BLP 10KV-330KV U120B 10KV-330KV
U100BLP1 10KV-330KV U160BS 10KV-500KV
U100BLP2 10KV-330KV U160BM 10KV-500KV
U120BP 10KV-330KV U160BL 10KV-500KV
U120BP1 10KV-330KV U210B 10KV-500KV
U120BP2 10KV-330KV U240B 10KV-500KV
U160BMP 10KV-500KV U300B 10KV-500KV
U160BLP 10KV-500KV U420B 10KV-500KV
U160BMP1 10KV-500KV U530B 10KV-1000KV
U160BLP1 10KV-500KV U550B 10KV-1000KV
U210BP 10KV-500KV Double sheds glass insulator U70BLD 10KV-330KV
U70BLP1 10KV-500KV U70BSD 10KV-330KV
U210BP1 10KV-500KV U100BLD 10KV-330KV
U240BP1 10KV-500KV U100BSD 10KV-330KV
U240BP2 10KV-500KV U120BLD 10KV-330KV
U300BP 10KV-500KV U160BLD 10KV-500KV
U300BP1 10KV-500KV U160BSD 10KV-500KV
Open profile glass insulator U70BSM 10KV-330KV U160BMD 10KV-500KV
U70BLM 10KV-330KV U210BD 10KV-500KV
U100BSM 10KV-330KV U240BD 10KV-500KV
U100BLM 10KV-330KV Ground profile glass insulator U70C 10KV-330KV
U120BLM 10KV-330KV U70CN 10KV-330KV
U160BSM 10KV-500KV U100C 10KV-330KV
U160BMM 10KV-500KV U100CN 10KV-330KV
U160BLM 10KV-500KV U100 Double Shell Two Winged Glass Insulator 146 280 450
U210BM 10KV-500KV
U240BM 10KV-500KV

Are there any specific applications for the U100b series electrical insulators?

  • U100b series electric insulators are specifically applied in high-voltage overhead power line systems, particularly for mechanical support and electrical insulation of conductors. Their typical applications include:
  • Use in power transmission and distribution lines where mechanical load capacity around 100 kN is required.
  • Installation as suspension or tension insulators in bare conductor lines to provide insulation and mechanical strength.
  • Suitable for polluted or high-contamination environments due to their design features such as double shell or double shed shapes that increase creepage distance and reduce leakage currents.
  • Often used in bird protection systems and dead-end strings in medium voltage networks (e.g., 15-66 kV), where they help maintain phase-earth safety distances and reduce electrocution risks.
  • Compatible with polymeric silicone coatings or covers to enhance hydrophobicity, UV resistance, and performance in saline or harsh weather conditions, extending service life beyond 20 years.
  • Employed in structural solutions for 2nd and 3rd category networks where bird perching deterrents and insulated surfaces are required to meet environmental and safety regulations.
