U40 U70BL U70BLP U120B U210BP Suspended Glass Insulator from NOOA ELECTRIC

Date:2024-09-04Tags:U40 Glass Insulator,U70B Suspended Glass Insulator,Custom Glass Insulator

Suspended glass insulator is a type of electrical insulator typically used in high-voltage power lines. These insulators are made from toughened or tempered glass, designed to support and electrically isolate the conductors from the physical structure they are attached to, such as a transmission tower. The "suspended" aspect refers to the way they are hung in series to form a string, allowing for greater flexibility and insulation strength.

Main Electric Insulators : Standard-Type Glass Insulator (U70/U120/U160/U210/U300) , Antipollution-Type Glass Insulators (U120bp/U160bsp/U210bp), Aerodynamic Type Glass Electrical Insulators (Ug70bsa/U100bsa/U120bla), Multi-Umbrella Type Electric Insulators, Ground-Wires Type Glass Power Line Insulators (U70cn/U100cn/U120c), Post Insulator For Line, Pin Glass Insulator. Products Are Mainly Used For Transmission Line Insulation, Suspension, Support, Tension Conductors. They Are Divided Into 5 Major Series: The Standard Type Glass Insulator 40-550kn, Filth-Resistant Type Glass Insulators 70-420kn, Aerodynamic Type Glass Electrical Insulators 120-300kn, Multi-Umbrella Type Electric Insulators 120-300kn, And Ground Circuit Type High Voltage Insulators, Able To Be Used For Line Voltage From 10kv～1000kv. More details as below:

basic type figure no. minimum mechanical failing load(kn) nominal diameter d(mm) nominal spacing p(mm) nominal creepage distance (mm) standard coupling wet power frequency withstand voltage (kv) dry lightning impulse withstand voltage (kv) power frequency puncture voltage (kv) radio interference voltage (μ v) 10kv 1mhz corona visual test p/c kv power frequency electric arc voltage impulse puncture voltage (p.u) net weight (kg)

u40b

1-3 40 178 110 190 11 25 50 90 50 18/22 0.12s/20ka 2.8 2.1
u70bs 1-3 70 255 127 320 16 40 100 130 50 18/22 0.12s/20ka 2.8 3.5
u70bl 1-3 70 255 146 320 16 40 100 130 50 18/22 0.12s/20ka 2.8 3.6
u100bs 1-3 100 255 146 320 16 40 100 130 50 18/22 0.12s/20ka 2.8 4
u120b 1-3 120 255 146 400 16 40 100 130 50 18/22 0.12s/20ka 2.8 4
u160bs 1-3 160 280 146 400 20 45 110 130 50 18/22 0.12s/20ka 2.8 6.5
u160bm 1-3 160 280 155 400 20 45 110 130 50 18/22 0.12s/20ka 2.8 6.6
u160bl 1-3 160 280 170 400 20 45 110 130 50 18/22 0.12s/20ka 2.8 6.7
u210b 1-3 210 280 170 400 20 45 110 130 50 18/22 0.12s/20ka 2.8 7.2
u240b 1-3 240 280 170 400 20/24 45 110 130 50 18/22 0.12s/20ka 2.8 7.2
u300b 1-3 300 320 195 485 24 50 130 130 50 18/22 0.12s/20ka 2.8 10.6
u420b 1-3 420 360 205 550 28 80 140 140 50 18/22 0.12s/20ka 2.8 16
u550b 1-3 550 380 240 600 32 55 140 140 50 18/22 0.12s/20ka 2.8 21.5

note:
1. the product model is in accordance with gb/t 7253-2005 and jb/t 9683-2012 (iec60305:1995, mod). the 420kn strength grade product contains 400kn strength grade, and the 550kn strength grade product contains 530kn strength grade.

2. the connection structure is in accordance with gb/t 4056-2008 (iec60120: 1984, mod) and bs 3288 part

3. according to the customer's request, the locking pin can be w-pin or r-pin. unless otherwise specified, u70~u120 adopts w pin, and other uses r pin.

4. black marks are hot sellers-your best Glass insulators choice for overhead power lines


U120B Suspension Tempered Glass Insulators

U120B Suspension Tempered Glass Insulators

U120B Suspension Tempered Glass Insulators

Why Buy Suspension Tempered Glass Insulators from NOOA Electric?

Nooa Eelctric has been specialized in manufacturing high Voltage and ultra high voltage Disc Glass insulator since 2002, Qualified Approval supplier to China State Power Grid with 16 years with 2 glass natural gas kiln production lines. The production Capacity is 3500000 pieces per year, and now setting up the new kiln and lines up to 10500000 pieces per year.


1. Chinese Professional Electrical Insulators Manufacturer With A Complete Range Of Glass Insulators, Porcelain Insulators And Composite Insulators

2. Over 22-year R&d and Production Experience in Glass Insulators with 70000 sqm Factory, more than 200 employees, including 25 technicians

3. Provide Full Range of Electrical Glass Insulators: 40-550kN, 70-300kN, 70-240kN With Free Drawings & Approved Type Test Report.

4. INTERTEK, SGS, BV, etc. Any Third Party Inspection Before Delivery Is Available

5. Negotiable Payment Term & Bulk Stock With Fast Delivery（Ship in 1 Month）

6. Test Center For Glass Insulator. Inquire Now: info@nooaelectric.com, whatsapp: +86 19892857619.


U120B Suspension Tempered Glass Insulators

Get Free Quotation Now!

Any powerline insulators needs or inquiries, pls leave a message to us. More details, Faster response!
